Building a True Unattended SharePoint Online CSOM App in C# (Certificate-Based Entra ID App-Only) — Visual Studio Step-by-Step

This article walks you through creating a fully unattended (no interactive login) C# console app that:

Authenticates using Microsoft Entra ID App-Only
Uses a certificate (not a client secret)
Calls SharePoint Online CSOM (Microsoft.SharePoint.Client)
Creates a new item in a SharePoint list

Why certificate? Microsoft’s SharePoint guidance for Entra ID App-Only explicitly states that when doing app-only you must use a certificate to request access to SharePoint CSOM/REST APIs. (Microsoft Learn)

1) Background: Entra App-Only vs “Client Secret” confusion

Entra ID App-Only (modern model)

You register an app in Microsoft Entra ID
You assign SharePoint Application permissions (e.g., Sites.Selected or Sites.FullControl.All)
You authenticate app-only to SharePoint using a certificate (Microsoft Learn)
Your code uses MSAL:
- ConfidentialClientApplicationBuilder.WithCertificate(...) (Microsoft Learn)
- AcquireTokenForClient(...) (Microsoft Learn)

SharePoint App-Only (ACS legacy model)

There is an older “SharePoint App-Only” model (ACS) that historically used client id/secret and SharePoint add-in registration. It still exists for some scenarios, but it’s a different model than Entra App-Only. (Microsoft Learn)

If you’re using Entra App Registration + SharePoint Application permissions, follow the certificate path. (Microsoft Learn)

2) Prerequisites

Visual Studio 2022 (Community/Pro/Enterprise)
.NET 8 (or .NET 6/7)
A SharePoint Online site (example placeholder):
https://contoso.sharepoint.com/sites/DevSite
A target list (example placeholder):
Example List

3) Entra ID setup (UI steps)

Step 3.1 — Register the app

Go to Microsoft Entra ID
App registrations → New registration
Name: Contoso.SharePoint.Unattended.CSOM
Register

Step 3.2 — Add SharePoint Application permissions

You have two typical choices:

Option A: Tenant-wide power (simpler)

Add SharePoint Application permission: Sites.FullControl.All
Click Grant admin consent

Option B: Least privilege (recommended)

Add SharePoint Application permission: Sites.Selected
Click Grant admin consent
Then grant the app access to a specific site (see below)

To grant site access with PnP PowerShell (Sites.Selected), Microsoft community guidance commonly uses:

Grant-PnPAzureADAppSitePermission (pnp.github.io)

4) Create and upload the certificate

Step 4.1 — Create a self-signed cert (PowerShell)

Run PowerShell:

$cert = New-SelfSignedCertificate `
  -Subject "CN=Contoso.SharePoint.Unattended" `
  -CertStoreLocation "Cert:\CurrentUser\My" `
  -KeySpec Signature `
  -KeyExportPolicy Exportable `
  -KeyLength 2048 `
  -HashAlgorithm SHA256 `
  -NotAfter (Get-Date).AddYears(2)

$pwd = ConvertTo-SecureString -String "P@ssw0rd-ChangeMe!" -Force -AsPlainText

Export-PfxCertificate -Cert $cert -FilePath ".\sp-unattended.pfx" -Password $pwd
Export-Certificate   -Cert $cert -FilePath ".\sp-unattended.cer"

$cert.Thumbprint

Step 4.2 — Upload the certificate to your Entra App

Entra App → Certificates & secrets
Tab Certificates
Upload certificate
Upload sp-unattended.cer

The SharePoint guidance highlights that possession of the certificate/private key effectively gives whoever holds it the app’s permissions—treat it like a credential. (Microsoft Learn)

5) Visual Studio project (UI steps)

Step 5.1 — Create the project

Visual Studio → Create a new project
Choose Console App (C#)
Framework: .NET 8
Name: SharePoint.Unattended.CsomDemo

Step 5.2 — Install NuGet packages

Right-click project → Manage NuGet Packages → install:

Microsoft.Identity.Client (MSAL) (Microsoft Learn)
Microsoft.SharePointOnline.CSOM (NuGet)

Step 5.3 — Add `appsettings.json`

Add a JSON file named appsettings.json and set:

Copy to Output Directory → Copy if newer

Example appsettings.json (placeholders):

{
  "TenantId": "YOUR_TENANT_ID_GUID",
  "ClientId": "YOUR_APP_CLIENT_ID_GUID",
  "SharePointSiteUrl": "https://contoso.sharepoint.com/sites/DevSite",

  "PfxPath": "sp-unattended.pfx",
  "PfxPassword": "P@ssw0rd-ChangeMe!",

  "ListTitle": "Example List",
  "ItemTitle": "Created by unattended CSOM app",
  "ItemBody": "Hello from certificate-based Entra app-only."
}

Tip (Visual Studio workflow): Add sp-unattended.pfx to the project and set Copy to Output Directory → Copy if newer.

6) Full working code (MSAL certificate + CSOM + create list item)

Replace your Program.cs with the full code below.

using System;
using System.IO;
using System.Security.Cryptography.X509Certificates;
using System.Text.Json;
using System.Threading.Tasks;
using Microsoft.Identity.Client;
using Microsoft.SharePoint.Client;

internal class AppConfig
{
    public string TenantId { get; set; } = "";
    public string ClientId { get; set; } = "";
    public string SharePointSiteUrl { get; set; } = "";

    public string PfxPath { get; set; } = "";
    public string PfxPassword { get; set; } = "";

    public string ListTitle { get; set; } = "";
    public string ItemTitle { get; set; } = "Created by unattended CSOM app";
    public string ItemBody { get; set; } = "";
}

internal static class Program
{
    public static async Task<int> Main()
    {
        try
        {
            var config = LoadConfig("appsettings.json");
            ValidateConfig(config);

            Console.WriteLine("=== CONFIG ===");
            Console.WriteLine("SiteUrl  : " + config.SharePointSiteUrl);
            Console.WriteLine("ListTitle: " + config.ListTitle);

            // 1) Load certificate
            var cert = LoadCertificateFromPfx(config.PfxPath, config.PfxPassword);

            // 2) Acquire app-only token for SharePoint
            var accessToken = await AcquireSharePointTokenWithCertificateAsync(
                tenantId: config.TenantId,
                clientId: config.ClientId,
                certificate: cert,
                siteUrl: config.SharePointSiteUrl);

            // 3) Use CSOM with Bearer token
            using (var ctx = new ClientContext(config.SharePointSiteUrl))
            {
                ctx.ExecutingWebRequest += (sender, e) =>
                {
                    e.WebRequestExecutor.RequestHeaders["Authorization"] = "Bearer " + accessToken;
                };

                // Sanity check: load web
                var web = ctx.Web;
                ctx.Load(web, w => w.Title, w => w.Url);
                ctx.ExecuteQuery();

                Console.WriteLine("SUCCESS (Web loaded)");
                Console.WriteLine("Site: " + web.Title);
                Console.WriteLine("Url : " + web.Url);

                // Create list item
                CreateListItem(ctx, config.ListTitle, config.ItemTitle, config.ItemBody);
            }

            return 0;
        }
        catch (Exception ex)
        {
            Console.WriteLine("ERROR");
            Console.WriteLine(ex);
            return 1;
        }
    }

    private static void CreateListItem(ClientContext ctx, string listTitle, string itemTitle, string itemBody)
    {
        if (string.IsNullOrWhiteSpace(listTitle))
            throw new Exception("ListTitle is required in appsettings.json");

        var list = ctx.Web.Lists.GetByTitle(listTitle);

        var itemCreateInfo = new ListItemCreationInformation();
        var item = list.AddItem(itemCreateInfo);

        // Most lists have 'Title'
        item["Title"] = itemTitle ?? "";

        // Optional field: 'Body' exists only on some list templates
        if (!string.IsNullOrWhiteSpace(itemBody))
        {
            try { item["Body"] = itemBody; }
            catch { /* ignore if field doesn't exist */ }
        }

        item.Update();
        ctx.Load(item, i => i.Id);
        ctx.ExecuteQuery();

        Console.WriteLine("SUCCESS (Item created)");
        Console.WriteLine("New Item ID: " + item.Id);
    }

    private static AppConfig LoadConfig(string fileName)
    {
        if (!System.IO.File.Exists(fileName))
            throw new FileNotFoundException("Config file not found: " + fileName);

        var json = System.IO.File.ReadAllText(fileName);

        var cfg = JsonSerializer.Deserialize<AppConfig>(json, new JsonSerializerOptions
        {
            PropertyNameCaseInsensitive = true
        });

        if (cfg == null)
            throw new InvalidOperationException("Failed to parse config file.");

        return cfg;
    }

    private static void ValidateConfig(AppConfig cfg)
    {
        if (string.IsNullOrWhiteSpace(cfg.TenantId)) throw new Exception("TenantId is required.");
        if (string.IsNullOrWhiteSpace(cfg.ClientId)) throw new Exception("ClientId is required.");
        if (string.IsNullOrWhiteSpace(cfg.SharePointSiteUrl)) throw new Exception("SharePointSiteUrl is required.");
        if (string.IsNullOrWhiteSpace(cfg.PfxPath)) throw new Exception("PfxPath is required.");
        if (string.IsNullOrWhiteSpace(cfg.PfxPassword)) throw new Exception("PfxPassword is required.");
        if (string.IsNullOrWhiteSpace(cfg.ListTitle)) throw new Exception("ListTitle is required.");
    }

    private static X509Certificate2 LoadCertificateFromPfx(string pfxPath, string password)
    {
        if (!System.IO.File.Exists(pfxPath))
            throw new FileNotFoundException("PFX file not found: " + pfxPath);

        return new X509Certificate2(
            pfxPath,
            password,
            X509KeyStorageFlags.MachineKeySet |
            X509KeyStorageFlags.Exportable);
    }

    private static async Task<string> AcquireSharePointTokenWithCertificateAsync(
        string tenantId,
        string clientId,
        X509Certificate2 certificate,
        string siteUrl)
    {
        // SharePoint resource scope must be https://{tenant}.sharepoint.com/.default
        var spHost = new Uri(siteUrl).GetLeftPart(UriPartial.Authority);
        var scopes = new[] { spHost + "/.default" };

        var app = ConfidentialClientApplicationBuilder
            .Create(clientId)
            .WithTenantId(tenantId)
            .WithCertificate(certificate) // certificate-based confidential client :contentReference[oaicite:10]{index=10}
            .Build();

        var result = await app.AcquireTokenForClient(scopes).ExecuteAsync(); // client-credentials flow :contentReference[oaicite:11]{index=11}

        if (string.IsNullOrWhiteSpace(result.AccessToken))
            throw new Exception("Access token is empty.");

        return result.AccessToken;
    }
}

7) Run and verify

Press F5.

Expected output pattern:

Token acquired
Web loaded (site title)
Item created + new Item ID

8) Sites.Selected: grant access to a specific site (PnP PowerShell)

If you used Sites.Selected, you must grant the app permission to your target site. A common approach is PnP PowerShell:

Grant-PnPAzureADAppSitePermission -AppId <GUID> -Permissions <Read|Write|Manage|FullControl> -Site <url> (pnp.github.io)

This is the key detail many people miss: Sites.Selected alone grants nothing until you assign site permissions. (pnp.github.io)

9) Hardening for real unattended execution (Scheduled Task / Service)

Store the certificate more securely

Instead of shipping a .pfx alongside the exe:

Import the cert into Local Machine certificate store
Load it by thumbprint
Or store it in a secure vault and retrieve it at runtime

This reduces the risk of someone copying the PFX and gaining your app’s permissions—an explicit risk called out in SharePoint’s certificate-based app-only model. (Microsoft Learn)

10) Troubleshooting checklist

401 Unauthorized

Most common causes:

Wrong token audience (Graph token instead of SharePoint token)
Missing SharePoint app permissions / consent not granted
Using secret with Entra app-only + CSOM/REST (certificate is the supported path in SharePoint guidance) (Microsoft Learn)

“List does not exist”

ListTitle must match the SharePoint list display name exactly.

“The field ‘Title’ does not exist”

Some lists/libraries don’t use Title. Use the correct internal field name for that list type.

Summary table — Build steps

Step	Action
1	Register Entra ID App
2	Add SharePoint Application permissions + admin consent
3	Create cert (PFX/CER) and upload CER to the app
4	Create Console App in Visual Studio
5	Install `Microsoft.Identity.Client` + `Microsoft.SharePointOnline.CSOM` (NuGet)
6	Add `appsettings.json` and certificate settings
7	Implement MSAL `WithCertificate` + `AcquireTokenForClient` (Microsoft Learn)
8	Inject `Authorization: Bearer` into CSOM and create list item
9	(Optional) For `Sites.Selected`, grant site permission (pnp.github.io)

Summary table — Technical essentials

Topic	What matters
Why certificate	SharePoint Entra App-Only guidance requires certificate for CSOM/REST (Microsoft Learn)
Token flow	`AcquireTokenForClient` is the client-credentials flow (no user) (Microsoft Learn)
MSAL setup	`WithCertificate(X509Certificate2)` configures the confidential client (Microsoft Learn)
CSOM package	Use `Microsoft.SharePointOnline.CSOM` (NuGet)
Least privilege	`Sites.Selected` + per-site grants via PnP cmdlet (pnp.github.io)
Legacy vs modern	ACS app-only differs from Entra app-only; modernization guidance exists (Microsoft Learn)
