Microsoft Graph + SharePoint End-to-End (Production Guide with `Sites.Selected`)

This article shows a complete, production-grade path to use Microsoft Graph with SharePoint Online using least privilege via Sites.Selected: from app registration and consent, to granting access to a specific site, and finally performing real SharePoint operations (like creating list items) with app-only authentication.
Key idea: Sites.Selected grants nothing by itself—you must assign site permissions explicitly. (Microsoft Learn)

0) Why `Sites.Selected` exists (and why you should care)

Traditional Graph application permissions like Sites.Read.All / Sites.ReadWrite.All are powerful: once admin-consented, the app can access all sites in the tenant (within that permission). Sites.Selected was introduced to support resource-specific consent so you can grant an application access to only specific site collections. (Microsoft Learn)

Reality check: after consenting Sites.Selected, your app still has no access until you grant it permissions for a target site. (Microsoft Learn)

1) Architecture pattern (recommended)

In real environments, you almost always end up with two roles:

A) “Worker app” (least privilege)

Has Graph Application permission: Sites.Selected
Runs unattended (service/daemon) to do real work (list items, files, pages, etc.)

B) “Manager” (admin) mechanism to assign site access

You need something with admin capability to run the grant step, such as:

PnP PowerShell as a one-time admin action, or (PnP GitHub)
A separate Manager app with enough rights to call POST /sites/{site-id}/permissions (admin-only operation in practice) (Microsoft Learn)

You can still do everything in one console tool for demo purposes, but conceptually these responsibilities differ.

2) Step-by-step: Entra ID App Registration (Worker app)

Step 2.1 — Register the app

Create an app registration in Microsoft Entra ID for your worker.

Step 2.2 — Add Graph permission

Add Microsoft Graph → Application permissions → Sites.Selected and then Grant admin consent. (Microsoft Learn)

3) Step-by-step: Find the target Site ID (Graph)

To grant permissions or call SharePoint resources, you often need the site ID.

Use Get site by path:
GET https://graph.microsoft.com/v1.0/sites/{hostname}:/{server-relative-path} (Microsoft Learn)

Example (placeholders):

Hostname: contoso.sharepoint.com
Path: /sites/ExampleSite

4) Step-by-step: Grant site permissions to the Worker app

Option A — Grant with Microsoft Graph (REST)

Use Create permission on a site:
POST /sites/{site-id}/permissions (Microsoft Learn)

Example body (write access):

{
  "roles": ["write"],
  "grantedToIdentities": [
    {
      "application": {
        "id": "WORKER-APP-CLIENT-ID-GUID",
        "displayName": "Contoso.SharePoint.Worker"
      }
    }
  ]
}

This creates an application permission on that site (not a user permission). (Microsoft Learn)

Option B — Grant with PnP PowerShell (simplest admin experience)

PnP provides Grant-PnPAzureADAppSitePermission, designed exactly for Sites.Selected. (PnP GitHub)

# Requires an admin-authenticated PnP connection to the target site
Connect-PnPOnline -Url "https://contoso.sharepoint.com/sites/ExampleSite" -Interactive

Grant-PnPAzureADAppSitePermission `
  -AppId "WORKER-APP-CLIENT-ID-GUID" `
  -DisplayName "Contoso.SharePoint.Worker" `
  -Permissions Write

5) Step-by-step: Perform SharePoint operations with Graph (Worker app)

Once the Worker app has:

Sites.Selected consented, and
explicit site permission assigned (read/write),

…it can call SharePoint Graph endpoints for that site. (Microsoft Learn)

5.1 Create a SharePoint list item (Graph)

Use:
POST /sites/{site-id}/lists/{list-id}/items with a fields object. (Microsoft Learn)

6) Full working example (C#): grant site permission + create a list item

This sample demonstrates the end-to-end flow:

Manager credentials (admin-capable) grant the permission on the site
Worker credentials (Sites.Selected) create the list item

In real production, the “grant” step is typically done once (PowerShell/automation), while the Worker runs daily/hourly.

`appsettings.json`

{
  "TenantId": "00000000-0000-0000-0000-000000000000",

  "ManagerApp": {
    "ClientId": "11111111-1111-1111-1111-111111111111",
    "ClientSecret": "MANAGER-APP-SECRET"
  },

  "WorkerApp": {
    "ClientId": "22222222-2222-2222-2222-222222222222",
    "ClientSecret": "WORKER-APP-SECRET",
    "DisplayName": "Contoso.SharePoint.Worker"
  },

  "Target": {
    "Hostname": "contoso.sharepoint.com",
    "SiteServerRelativePath": "/sites/ExampleSite",
    "ListDisplayName": "Example List",
    "NewItemTitle": "Created by Sites.Selected worker"
  }
}

`Program.cs` (full code)

using System;
using System.IO;
using System.Linq;
using System.Net;
using System.Net.Http;
using System.Net.Http.Headers;
using System.Text;
using System.Text.Json;
using System.Threading.Tasks;
using Microsoft.Identity.Client;

internal sealed class RootConfig
{
    public string TenantId { get; set; } = "";

    public AppSecretConfig ManagerApp { get; set; } = new();
    public WorkerConfig WorkerApp { get; set; } = new();
    public TargetConfig Target { get; set; } = new();
}

internal sealed class AppSecretConfig
{
    public string ClientId { get; set; } = "";
    public string ClientSecret { get; set; } = "";
}

internal sealed class WorkerConfig : AppSecretConfig
{
    public string DisplayName { get; set; } = "Contoso.SharePoint.Worker";
}

internal sealed class TargetConfig
{
    public string Hostname { get; set; } = "contoso.sharepoint.com";
    public string SiteServerRelativePath { get; set; } = "/sites/ExampleSite";
    public string ListDisplayName { get; set; } = "Example List";
    public string NewItemTitle { get; set; } = "Created by Sites.Selected worker";
}

internal static class Program
{
    private static readonly string[] GraphScopes = new[] { "https://graph.microsoft.com/.default" };
    private const string GraphBase = "https://graph.microsoft.com/v1.0";

    public static async Task<int> Main()
    {
        try
        {
            var cfg = LoadConfig("appsettings.json");
            Validate(cfg);

            // 1) Resolve target siteId
            var managerToken = await AcquireAppOnlyTokenAsync(cfg.TenantId, cfg.ManagerApp.ClientId, cfg.ManagerApp.ClientSecret);
            var site = await GetSiteByPathAsync(managerToken, cfg.Target.Hostname, cfg.Target.SiteServerRelativePath);
            Console.WriteLine($"Site resolved: {site.Id} ({site.WebUrl})");

            // 2) Grant site permission to the Worker app (roles: write)
            await GrantWorkerAppSitePermissionAsync(
                managerToken,
                site.Id,
                cfg.WorkerApp.ClientId,
                cfg.WorkerApp.DisplayName,
                role: "write"
            );
            Console.WriteLine("Granted worker app site permission: write");

            // 3) Worker app uses Sites.Selected to operate on this site
            var workerToken = await AcquireAppOnlyTokenAsync(cfg.TenantId, cfg.WorkerApp.ClientId, cfg.WorkerApp.ClientSecret);

            // 4) Find listId by display name
            var listId = await FindListIdByDisplayNameAsync(workerToken, site.Id, cfg.Target.ListDisplayName);
            Console.WriteLine($"List resolved: {cfg.Target.ListDisplayName} -> {listId}");

            // 5) Create list item
            var newItemId = await CreateListItemAsync(workerToken, site.Id, listId, cfg.Target.NewItemTitle);
            Console.WriteLine($"List item created. Item id: {newItemId}");

            return 0;
        }
        catch (Exception ex)
        {
            Console.Error.WriteLine("FAILED:");
            Console.Error.WriteLine(ex);
            return 1;
        }
    }

    // -------------------- Config --------------------

    private static RootConfig LoadConfig(string path)
    {
        var json = File.ReadAllText(path);
        return JsonSerializer.Deserialize<RootConfig>(json, new JsonSerializerOptions
        {
            PropertyNameCaseInsensitive = true
        }) ?? throw new InvalidOperationException("Invalid appsettings.json");
    }

    private static void Validate(RootConfig cfg)
    {
        if (string.IsNullOrWhiteSpace(cfg.TenantId)) throw new ArgumentException("TenantId is required.");

        if (string.IsNullOrWhiteSpace(cfg.ManagerApp.ClientId)) throw new ArgumentException("ManagerApp.ClientId is required.");
        if (string.IsNullOrWhiteSpace(cfg.ManagerApp.ClientSecret)) throw new ArgumentException("ManagerApp.ClientSecret is required.");

        if (string.IsNullOrWhiteSpace(cfg.WorkerApp.ClientId)) throw new ArgumentException("WorkerApp.ClientId is required.");
        if (string.IsNullOrWhiteSpace(cfg.WorkerApp.ClientSecret)) throw new ArgumentException("WorkerApp.ClientSecret is required.");

        if (string.IsNullOrWhiteSpace(cfg.Target.Hostname)) throw new ArgumentException("Target.Hostname is required.");
        if (string.IsNullOrWhiteSpace(cfg.Target.SiteServerRelativePath)) throw new ArgumentException("Target.SiteServerRelativePath is required.");
        if (!cfg.Target.SiteServerRelativePath.StartsWith("/")) throw new ArgumentException("Target.SiteServerRelativePath must start with '/'.");
        if (string.IsNullOrWhiteSpace(cfg.Target.ListDisplayName)) throw new ArgumentException("Target.ListDisplayName is required.");
    }

    // -------------------- Auth --------------------

    private static async Task<string> AcquireAppOnlyTokenAsync(string tenantId, string clientId, string clientSecret)
    {
        var app = ConfidentialClientApplicationBuilder
            .Create(clientId)
            .WithClientSecret(clientSecret)
            .WithAuthority($"https://login.microsoftonline.com/{tenantId}")
            .Build();

        var result = await app.AcquireTokenForClient(GraphScopes).ExecuteAsync();
        return result.AccessToken;
    }

    // -------------------- Graph helpers --------------------

    private static HttpClient CreateHttp(string token)
    {
        var http = new HttpClient();
        http.DefaultRequestHeaders.Authorization = new AuthenticationHeaderValue("Bearer", token);
        http.DefaultRequestHeaders.Accept.Add(new MediaTypeWithQualityHeaderValue("application/json"));
        return http;
    }

    private static async Task<string> SendWithRetryAsync(HttpClient http, HttpMethod method, string url, string? jsonBody = null)
    {
        const int maxAttempts = 6;
        var attempt = 0;

        while (true)
        {
            attempt++;

            using var req = new HttpRequestMessage(method, url);
            if (jsonBody != null)
            {
                req.Content = new StringContent(jsonBody, Encoding.UTF8, "application/json");
            }

            using var resp = await http.SendAsync(req);
            var body = await resp.Content.ReadAsStringAsync();

            if ((int)resp.StatusCode == 429)
            {
                if (attempt >= maxAttempts)
                    throw new HttpRequestException("Too many throttled attempts (429).");

                var delaySeconds = 30;
                if (resp.Headers.RetryAfter?.Delta != null)
                    delaySeconds = (int)Math.Ceiling(resp.Headers.RetryAfter.Delta.Value.TotalSeconds);

                await Task.Delay(TimeSpan.FromSeconds(delaySeconds));
                continue;
            }

            if (!resp.IsSuccessStatusCode)
            {
                throw new HttpRequestException(
                    $"Graph call failed: {(int)resp.StatusCode} {resp.ReasonPhrase}\nURL: {url}\nBODY:\n{body}"
                );
            }

            return body;
        }
    }

    // -------------------- Step: Resolve site --------------------

    private sealed record SiteInfo(string Id, string WebUrl);

    private static async Task<SiteInfo> GetSiteByPathAsync(string token, string hostname, string serverRelativePath)
    {
        // GET /sites/{hostname}:/{server-relative-path}
        // Docs: Get SharePoint site by path
        var url = $"{GraphBase}/sites/{hostname}:{serverRelativePath}";
        using var http = CreateHttp(token);

        var json = await SendWithRetryAsync(http, HttpMethod.Get, url);
        using var doc = JsonDocument.Parse(json);

        var id = doc.RootElement.GetProperty("id").GetString() ?? "";
        var webUrl = doc.RootElement.TryGetProperty("webUrl", out var w) ? (w.GetString() ?? "") : "";

        if (string.IsNullOrWhiteSpace(id))
            throw new InvalidOperationException("Could not resolve site id.");

        return new SiteInfo(id, webUrl);
    }

    // -------------------- Step: Grant Sites.Selected access --------------------

    private static async Task GrantWorkerAppSitePermissionAsync(
        string managerToken,
        string siteId,
        string workerAppId,
        string workerDisplayName,
        string role)
    {
        // POST /sites/{site-id}/permissions
        // Creates an application permission on a site
        var url = $"{GraphBase}/sites/{siteId}/permissions";

        var payload = new
        {
            roles = new[] { role },
            grantedToIdentities = new[]
            {
                new
                {
                    application = new
                    {
                        id = workerAppId,
                        displayName = workerDisplayName
                    }
                }
            }
        };

        using var http = CreateHttp(managerToken);
        var jsonBody = JsonSerializer.Serialize(payload);

        await SendWithRetryAsync(http, HttpMethod.Post, url, jsonBody);
    }

    // -------------------- Step: Find list by display name --------------------

    private static async Task<string> FindListIdByDisplayNameAsync(string token, string siteId, string listDisplayName)
    {
        // Enumerate lists and find by displayName
        // Pattern docs: Working with SharePoint sites in Microsoft Graph
        var url = $"{GraphBase}/sites/{siteId}/lists?$select=id,displayName&$top=200";

        using var http = CreateHttp(token);
        var json = await SendWithRetryAsync(http, HttpMethod.Get, url);
        using var doc = JsonDocument.Parse(json);

        var values = doc.RootElement.GetProperty("value").EnumerateArray();
        foreach (var item in values)
        {
            var dn = item.GetProperty("displayName").GetString() ?? "";
            if (string.Equals(dn, listDisplayName, StringComparison.OrdinalIgnoreCase))
            {
                var id = item.GetProperty("id").GetString() ?? "";
                if (!string.IsNullOrWhiteSpace(id)) return id;
            }
        }

        throw new InvalidOperationException($"List not found: '{listDisplayName}'.");
    }

    // -------------------- Step: Create list item --------------------

    private static async Task<string> CreateListItemAsync(string token, string siteId, string listId, string title)
    {
        // POST /sites/{site-id}/lists/{list-id}/items
        // Body: { "fields": { "Title": "..." } }
        var url = $"{GraphBase}/sites/{siteId}/lists/{listId}/items";

        var payload = new
        {
            fields = new
            {
                Title = title
            }
        };

        using var http = CreateHttp(token);
        var jsonBody = JsonSerializer.Serialize(payload);

        var json = await SendWithRetryAsync(http, HttpMethod.Post, url, jsonBody);
        using var doc = JsonDocument.Parse(json);

        // Graph returns listItem with "id" (string)
        var itemId = doc.RootElement.GetProperty("id").GetString() ?? "";
        return itemId;
    }
}

Why these endpoints are “the correct primitives”

Get site by path: GET /sites/{hostname}:/{relative-path} (Microsoft Learn)
Create site permission: POST /sites/{site-id}/permissions creates an application permission (Microsoft Learn)
Create list item: POST /sites/{site-id}/lists/{list-id}/items with fields (Microsoft Learn)

7) Troubleshooting (the stuff that usually breaks)

Problem: 403 Forbidden after consenting `Sites.Selected`

That’s expected if you didn’t grant site permission yet. Sites.Selected alone doesn’t allow access. (Microsoft Learn)

Problem: Grant call fails / permission not applied

Ensure you’re using a principal with sufficient rights to grant application permissions on sites (commonly an admin workflow). (Microsoft Learn)
For simpler governance, use PnP’s cmdlets. (PnP GitHub)

Problem: You can’t find the site

Use the “get by path” endpoint and validate the server-relative path format. (Microsoft Learn)

8) Production hardening checklist

Least privilege

Prefer Sites.Selected + explicit site grants over tenant-wide permissions. (Microsoft Learn)

Reliability

Implement retry for 429 throttling and honor Retry-After (already in the code). (General Graph best practice; throttling is normal at scale.)

Maintainability

Separate “grant” workflow from the worker runtime.
Log: siteId, listId, Graph request IDs, and failures with payload snippets.

References (official/high-signal)

Create site permission (POST /sites/{site-id}/permissions) (Microsoft Learn)
Selected permissions overview (core concept: “consent + assignment + token”) (Microsoft Learn)
SharePoint resource patterns in Graph (Microsoft Learn)
Get site by path (Microsoft Learn)
Create list item (Microsoft Learn)
Resource-specific consent (SharePoint guidance + PnP cmdlets mention) (Microsoft Learn)
PnP PowerShell: Grant-PnPAzureADAppSitePermission (PnP GitHub)

Summary tables

A) End-to-end steps

Step	Action	Outcome
1	Register Worker app in Entra ID	App identity created
2	Add Graph Application permission `Sites.Selected` + admin consent	Worker can potentially be authorized (but still has no site access) (Microsoft Learn)
3	Resolve site ID with `GET /sites/{hostname}:/{path}`	You have the `siteId` (Microsoft Learn)
4	Grant site permission `POST /sites/{siteId}/permissions` (or PnP cmdlet)	Worker gains `read`/`write` on that specific site (Microsoft Learn)
5	Worker uses `POST /sites/{siteId}/lists/{listId}/items`	List item created successfully (Microsoft Learn)

B) Technical takeaways

Topic	Rule
`Sites.Selected`	Grants zero access until you assign permissions on the target site (Microsoft Learn)
Granting	`POST /sites/{site-id}/permissions` creates application site permission (Microsoft Learn)
Site resolution	Use `GET /sites/{hostname}:/{server-relative-path}` (Microsoft Learn)
List item creation	Use `POST /sites/{siteId}/lists/{listId}/items` with `fields` (Microsoft Learn)
Ops	Build retries for 429 and log failures (production requirement)

edvaldo b. guimarães filho

Microsoft Graph + SharePoint End-to-End (Production Guide with Sites.Selected)

Microsoft Graph + SharePoint End-to-End (Production Guide with `Sites.Selected`)

0) Why `Sites.Selected` exists (and why you should care)

1) Architecture pattern (recommended)

A) “Worker app” (least privilege)

B) “Manager” (admin) mechanism to assign site access

2) Step-by-step: Entra ID App Registration (Worker app)

Step 2.1 — Register the app

Step 2.2 — Add Graph permission

3) Step-by-step: Find the target Site ID (Graph)

4) Step-by-step: Grant site permissions to the Worker app

Option A — Grant with Microsoft Graph (REST)

Option B — Grant with PnP PowerShell (simplest admin experience)

5) Step-by-step: Perform SharePoint operations with Graph (Worker app)

5.1 Create a SharePoint list item (Graph)

6) Full working example (C#): grant site permission + create a list item

`appsettings.json`

`Program.cs` (full code)

Why these endpoints are “the correct primitives”

7) Troubleshooting (the stuff that usually breaks)

Problem: 403 Forbidden after consenting `Sites.Selected`

Problem: Grant call fails / permission not applied

Problem: You can’t find the site

8) Production hardening checklist

Least privilege

Reliability

Maintainability

References (official/high-signal)

Summary tables

A) End-to-end steps

B) Technical takeaways

Microsoft Graph + SharePoint End-to-End (Production Guide with Sites.Selected)

0) Why Sites.Selected exists (and why you should care)

1) Architecture pattern (recommended)

A) “Worker app” (least privilege)

B) “Manager” (admin) mechanism to assign site access

2) Step-by-step: Entra ID App Registration (Worker app)

Step 2.1 — Register the app

Step 2.2 — Add Graph permission

3) Step-by-step: Find the target Site ID (Graph)

4) Step-by-step: Grant site permissions to the Worker app

Option A — Grant with Microsoft Graph (REST)

Option B — Grant with PnP PowerShell (simplest admin experience)

5) Step-by-step: Perform SharePoint operations with Graph (Worker app)

5.1 Create a SharePoint list item (Graph)

6) Full working example (C#): grant site permission + create a list item

appsettings.json

Program.cs (full code)

Why these endpoints are “the correct primitives”

7) Troubleshooting (the stuff that usually breaks)

Problem: 403 Forbidden after consenting Sites.Selected

Problem: Grant call fails / permission not applied

Problem: You can’t find the site

8) Production hardening checklist

Least privilege

Reliability

Maintainability

References (official/high-signal)

Summary tables

A) End-to-end steps

B) Technical takeaways

Share this:

Microsoft Graph + SharePoint End-to-End (Production Guide with `Sites.Selected`)

0) Why `Sites.Selected` exists (and why you should care)

`appsettings.json`

`Program.cs` (full code)

Problem: 403 Forbidden after consenting `Sites.Selected`
