Step 9 — Visualizing Word Co-occurrence (Bigrams) as Networks in Python

Introduction

After learning how to count word co-occurrence (bigrams) in Step 8, it’s time to progress into seeing these relationships visually. Visualizing bigrams as a network (graph) helps you quickly spot the most important word associations in your data. In this article, you’ll learn how to turn your bigram co-occurrence statistics into an interpretable network using Python’s networkx and matplotlib libraries.

Main concept explained clearly

A network graph (also called a “graph” in mathematics and computer science) is a collection of points (nodes) connected by lines (edges). In NLP bigram analysis:

• Each node represents a unique word.
• Each edge between two nodes represents a bigram (a pair of consecutive words).
• The weight of each edge is the count of how often that bigram appeared.

By converting bigrams and their counts into a network, you can:

• Spot clusters of terms that occur together.
• Identify “hub words” that connect different concepts.
• Visualize the most meaningful relationships in your text.

Why this matters in NLP

• Word networks capture context and association far better than isolated word counts.
• Visual networks help you understand text structure, spot common phrases, and find emerging topics.
• This approach is a first step toward topic modeling, phrase extraction, or even building word embeddings.
• Network graphs are valuable for presentations, making text analysis results more accessible and impactful.

Python example

Let’s turn a small text into a bigram network graph!

Step 9.1 — Prepare bigram data

Reuse your filtering and bigram code:

import string
text = "Natural language processing makes machines understand human language. Processing language is complex and interesting."
stop_words = set([
    'the', 'is', 'in', 'it', 'by', 'and', 'a', 'of', 'to', 'for', 'on', 'o', 'a', 'de', 'em', 'para'
])
def preprocess(text):
    clean = text.strip().lower()
    translator = str.maketrans('', '', string.punctuation)
    no_punct = clean.translate(translator)
    tokens = no_punct.split()
    return [w for w in tokens if w not in stop_words]
tokens = preprocess(text)
bigram_counts = {}
for i in range(len(tokens) - 1):
    pair = (tokens[i], tokens[i+1])
    bigram_counts[pair] = bigram_counts.get(pair, 0) + 1

Step 9.2 — Build and display the bigram network

You need to install networkx if you haven’t:

pip install networkx matplotlib

Now plot the graph:

“`python name=step09_bigram_network_graph.py
import string
import networkx as nx
import matplotlib.pyplot as plt

text = “Natural language processing makes machines understand human language. Processing language is complex and interesting.”

stop_words = set([
‘the’, ‘is’, ‘in’, ‘it’, ‘by’, ‘and’, ‘a’, ‘of’, ‘to’, ‘for’, ‘on’, ‘o’, ‘a’, ‘de’, ’em’, ‘para’
])

def preprocess(text):
clean = text.strip().lower()
translator = str.maketrans(”, ”, string.punctuation)
no_punct = clean.translate(translator)
tokens = no_punct.split()
return [w for w in tokens if w not in stop_words]

tokens = preprocess(text)

Count bigrams

bigram_counts = {}
for i in range(len(tokens) – 1):
pair = (tokens[i], tokens[i+1])
bigram_counts[pair] = bigram_counts.get(pair, 0) + 1

Create network graph

G = nx.Graph()
for (w1, w2), count in bigram_counts.items():
G.add_edge(w1, w2, weight=count)

Draw graph

plt.figure(figsize=(8, 5))
pos = nx.spring_layout(G, seed=42) # reproducible layout
edges = G.edges()
weights = [G[u][v][‘weight’] for u,v in edges]
nx.draw(G, pos, with_labels=True, width=weights, node_color=’skyblue’, edge_color=’gray’, font_size=12)
plt.title(“Bigram Network Graph”)
plt.show()
“`

Line-by-line explanation of the code

• Preprocessing and bigram counting:
  Same process you know—prepare clean tokens, then count bigram frequencies.
• G = nx.Graph(): Creates a new empty undirected graph.
• G.add_edge(w1, w2, weight=count): Adds an edge for each bigram, with frequency as the weight.
• nx.spring_layout(G, seed=42): Chooses where to place nodes visually (spring model, for nice spread).
• nx.draw(...): Draws the network graph, adjusting node color, edge thickness (by weight), and text size.
• plt.title(...), plt.show(): Standard matplotlib chart labeling and display.

Practical notes

• You can build and visualize much larger networks from real datasets—just limit the number of edges to keep the figure readable.
• Edge thickness will vary if some bigrams are repeated; higher weights lead to thicker lines.
• Use G.number_of_edges() or G.number_of_nodes() to check network size.
• Try using different layouts (nx.circular_layout, nx.kamada_kawai_layout) for fun.
• For Portuguese, just update your stop word set and text.

Suggested mini exercise

1. Change the sample text to a small paragraph in Portuguese and see how the graph changes.
2. Use a longer text, then plot only the top 10 or 20 most frequent bigrams by filtering bigram_counts first.
3. Try playing with color, font size, or different networkx layout functions.
4. Add a printout of the ten most frequent bigrams below the chart.

Conclusion

Visualizing word co-occurrence as a network makes relationships in your data leap off the page. You’ve now learned to move from numbers to structure, uncovering the clusters and connections that shape real-world text. With these skills, you’re ready to explore document structure, context, and semantics at a higher level—setting up for collocations, keyphrase extraction, or word embedding models in future steps.
